KIT100/150M22 |100/150Hrs maintenance kit for Moster185 MY22 *

KIT100/150M22 100/150Hrs maintenance kit for Moster185 MY22 – Genuine Vittorazi Motors Parts



The KIT100/150M22 contains all of the parts required to do both the 100 hour maintenance as well as the 150 hours maintenance on your MY’22 Vittorazi Moster 185 Plus, all in one convenient package!  Vittorazi maintenance kits also offer a better value as compared to ordering all of the required parts individually!

Please note this mainentance kit does not include the piston.  Vittorazi recommends replacing the M010 piston at 150hrs with the piston corresponding to your cylinder size (A,B,C,D, or E).

The KIT100/150M22 includes the following:

1x AT093a Air-box rubber manifold with incorporated sponge

1x M005 Bearing 47/20/14 mm – C3 (Set of 2)

1x M006 Oil seal viton 20/35/7 mm (Set of 2)

1x M009 Piston roller bearing

15x M019 Copper lock nut high temperature 8 x 1,25 mm

2x M020 Spark plug NGK BR9ES

1x M021a Antivibration mount 30 x 30 mm – M8 x 15 mm (Set of 2)

1x M021b Antivibration mount 30 x 30 mm – M8 x 25 mm (Set of 2)

1x M021f Security band (Set of 2)

1x M025 Complete series of gaskets and O-ring

1x M031a Spark-plug cap (Selettra)

1x M043 Starter rope 2,20 meters

1x M082 Reed valve petal (Set of 2)

2x M094 Fixing band 50-70 mm

1x M097 Series membranes and Gaskets Walbro WB

1x M114 Bearing 42/20/12 mm (Set of 2)

1x M139 Exhaust spring (Set of 5)

1x M141a Fixing Kit for silencer’s bracket

1x M151a Antivibration mount 30 x 20 mm soft (left) 14/20 mm with Nuts

1x M151c Antivibration mount 30 x 20 mm hard (right) 14/14 mm with Nut

1x MP055k Kit Plastic hook (Set of 2) with Shim washers 12 x 18 mm (Set of 6) and Elastic ring

4x MP093d Snaplock female Ø 16 mm, grey

1x MP102 Complete clutch

5x MP105 Seeger Ø 35 mm DIN 472

1x MP106 Bearing 35/15/11 mm – 2Z and Bearing 35/15/11 mm – 2HRS

5x MP107 Seeger Ø 15 mm DIN 471

2x MP107a Drum/Pinion cap

1x MP117 Belt Poly V PJ483 13 grooves

1x MP140 Heat shrinkable tubing (Set of 5)

1x MP141 Security cable 45 cm with aluminum clamp (Set of 5)

1x MP159 Noise absorbent material with Rivets

1x MY200a Exhaust black, initial part

1x MY201 Exhaust flange with assembled Bushing 40/50 hours and Springs

For any additional help, please don’t hesitate to contact us!

For maintenance and installation help, please see the Vittorazi manuals and technical documents.
