KIT100/150A22 | 100/150Hrs maintenance kit for Atom80 MY22/MY25

KIT100/150A22 100/150Hrs maintenance kit for Atom80 MY’22 and MY’25 – Genuine Vittorazi Motors Parts

Does not include the piston, must be ordered apart according to the selection.

The KIT100/150A22contains all of the parts required to do the 100 hour maintenance on your MY’22 and MY’25 Vittorazi Atom 80, all in one convenient package!  Vittorazi maintenance kits also offer a better value as compared to ordering all of the required parts individually!

The KIT100/150A22includes the following:

1x AT006 Oil seal viton 20/30/7 mm (Set of 2)

1x AT009 Piston roller bearing

2x AT019 Lock nut high temperature 6 x 1 mm (Set of 5)

1x AT025 Complete series of gaskets and O-ring

1x AT082 Reed valve petal (Set of 2)

1x AT093a Air-box rubber manifold with incorporated sponge

2x AT160 Oil for reduction gear 30 ml

1x AT172 Exhaust manifold and O-rings, black

1x AT175 Exhaust compression spring and Lock nut 6MA DIN 980 (Set of 2)

1x AT184 Noise absorbent material with rivets (1 set)

1x F003 Bearing 47/20/14 mm – TVH – C3 (Set of 2)

5x M019 Copper lock nut high temperature 8 x 1,25 mm

2x M020 Spark plug NGK BR9ES

2x M021 Antivibration mount 30 x 30 mm – M8 x 20 mm (Set of 2)

1x M031a Antivibration mount 30 x 30 mm – M8 x 20 mm (Set of 2)

1x M043 Starter rope 2,20 meters

2x M094 Fixing band 50-70 mm

1x M097 Series membranes and Gaskets Walbro WB

1x M139 Exhaust spring (Set of 5)

1x M151c Antivibration mount 30 x 20 mm hard (right) 14/14 mm with Nut

1x MP055k Kit Plastic hook (Set of 2) with Shim washers 12 x 18 mm (Set of 6) and Elastic ring

4x MP093d Snaplock female Ø 16 mm, grey

1x MP140 Heat shrinkable tubing (Set of 5)

1x MP141 Security cable 45 cm with aluminum clamp (Set of 5)

For any additional help, please don’t hesitate to contact us!

For maintenance and installation help, please see the Vittorazi manuals and technical documents.
